Contactor de corriente definitiva, 220/208-240VCA, 3 polos, 75A
| Full Load Amps-Inductive | 30 A |
|---|---|
| Item | Definite Purpose Magnetic Contactor |
| Number of Poles | 1 |
| Coil Volts | 440 to 480V AC |
| Reversing | No |
| Height | 3.19 in |
| Width | 1.97 in |
| Depth | 2.46 in |
| Enclosure NEMA Rating | No Enclosure |
| Hz | 50/60 |
| Standards | REACH Art 33 |
| Series | 42 Series |
| Phase | Three |
| Horsepower @ Single Phase - 120V AC | 2 HP |
| LED Lighting Current Rating | Not Applicable |
| Mounting Postion | Vertical |
| Frame Size | Not Applicable |
| Reversing Capability | Non-Reversing |
| Tungsten Lighting Current Rating | Not Applicable |
| Coil Voltage | 380-440/440-480V AC |
| Number of Normally Open Main Contacts | 1 |
| Contact Material | Silver Cadmium Oxide |
| Overall Width | 1.97 in |
| Full Load Current - Inductive | 30 A |
| Number of Normally Closed Main Contacts | 0 |
| Frequency | 50/60 Hz |
| Mounting Hole Distance - Height | 1.77 in |
| Overall Depth | 2.46 in |
| Includes Shunt | Single Pole with Shunt |
| NEMA Enclosure Rating | No Enclosure |
| Overall Height | 3.19 in |
| Horsepower @ Three Phase - 240V AC | 7.5 HP |
| Mechanical Operating Durability | 250,000 |
| Fluorescent Lighting Current Rating | Not Applicable |
| Horsepower @ Three Phase - 600V AC | Not Rated |
| Resistance Properties | Weld Resistant |
| Terminal Connection Type | Terminals |
| Mounting Style | Surface |
| Maximum Voltage Rating | 600 V AC |
| Full Load Current - Resistive | 40 A |
| Input Control Type | Not Applicable |
| Auxiliary Contact Module Capacity | 0 |
| NEMA Enclosure Material | Not Applicable |
| Locked Rotor Load | 180 A @ 240V, 180 A @ 277V |
| Maximum Operating Temperature | 158 deg F |
| Horsepower @ Single Phase - 240V AC | 3 HP |
| Contactor Style | HVACR Definite Purpose Contactor |
| Mounting Hole Distance - Width | 1.61 in |
| Package Quantity | 1 |
