HMI
| Number of HW interfaces Industrial Ethernet | 1 |
|---|---|
| Display type | TFT |
| Supply voltage type | DC |
| Pressure output present | Yes |
| Number of HW interfaces serial RS485 | 1 |
| numeric keyboard present | Yes |
| Min. operating temperature | 0 degree_Celsius |
| Installation depth | 65 millimetre |
| max. number of pixels, horizontal | 800 |
| Bearing track assembly possible | No |
| wall mounting/direct mounting possible | No |
| Formulations present | Yes |
| number of system buttons | 0 |
| max. number of pixels, vertical | 480 |
| IO-link master present | No |
| Number of colors/shades of gray of the display | 16,777,216 |
| Number of online languages. | 32 |
| Number of HW interfaces Wireless | 0 |
| Display, color present | Yes |
| useable project memory/user memory | 12000 kilobyte |
| Max. operating temperature | 50 degree_Celsius |
| number of grey scales | 0 |
| number of programmable function keys | 0 |
| max. supply voltage with DC | 28.8 volt |
| Number of HW interfaces, other | 0 |
| Additional software components, loadable present | Yes |
| Process value display (output) possible | Yes |
| Height of front | 158 millimetre |
| Manufacturer product family | HMI |
| Manufacturer product root | Comfort Panel |
| description of product type | TP700 Comfort INOX |
| number of buttons with LED | 0 |
| Monitor diagonal | 7 in |
| Number of HW interfaces parallel | 0 |
| Number of HW interfaces serial RS422 | 0 |
| Width of front | 214 millimetre |
| Number of levels, password protection | 50 |
| Number of HW interfaces PROFINET | 1 |
| Touch screen present | Yes |
| Number of HW interfaces serial TTY | 0 |
| min. supply voltage with DC | 19 V |
| Alpha keyboard present | Yes |
| Number of HW interfaces serial RS232 | 0 |
| Message display present | Yes |
| Messaging system (including buffer and acknowledgement) present | Yes |
| SW interfaces present | No |
| Process value provision (input) possible | Yes |
| Package Quantity | 1 |
