The Siemens JXD62B225 is a 2 Pole thermal magnetic molded case circuit breaker with a current rating of 225 Amps and a voltage rating of 600VAC. It has an interrupting rating of 35kAIC at 480V. The JXD62B225 has a bolt-on connection type and includes long time and instantaneous trip functions.
| Brand | Siemens |
|---|---|
| Series | Sentron |
| Amperage | 225 |
| Voltage | 600VAC |
| Poles | 2 |
| Phase | 1 |
| Mounting Type | Bolt-On |
| Approval | UL, IEC |
| Interrupting Rating | 35kAIC at 480V |
| Frame Type | JXD |
| Connection Type | Bolt-On |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous Trip |
| Terminal Connection | Load Side Lug |
| Temperature Rating | 40 °C |
| Mpn | JXD62B225 |
| Upc | 783643212992 |
| Gtin | 783643212992 |
