UPS System, 800kVA, Standby, Out: 24V DC In: 24V DC
| Item | UPS System |
|---|---|
| UPS Type | Standby |
| Power Rating | 800 kVA |
| Mounting | DIN Rail |
| Wattage | 42 W |
| Input Voltage | 24V DC |
| Output Voltage | 24V DC |
| Backup Time (Half/Full Load) | 34 min/9 min |
| Outlet Type | Hardwired |
| Medical Grade | No |
| Number of Outlets | 0 |
| Input Current | 1.8 A |
| Height | 5 in |
| Depth | 8 in |
| Fax/Modem Line Protection | No |
| Standards | cCSAus, CE, CSA C22.2 No. 107.1, cULus-Listed, EAC, UL, UL 508 |
| Hz | 50/60 Hz |
| Transfer Time | 0 msec |
| Automatic Volts Regulation | No |
| Width | 8 in |
| Display Type | LED |
| Includes | For 24V DC Back-up in Combination with a 24V DC Switch Mode Power Supply |
| Special Features | Aging, and Charge Level, Automatic Detection of Battery Modules, Automatic Selection of Optimal Temperature-Controlled Charging, Battery Connection, Monitoring of Operational Readiness |
| VA Rating - UPS Systems | 800 VA |
| Cord Length | No Cord |
| NEMA Plug Configuration | Not Applicable |
| Ports | N/A |
| NEMA Receptacle Configuration | No Configuration |
| Phase | Not Applicable |
| Input Connection | Hardwired |
| Housing Material | Metal |
| closed (sealed) | Yes |
| Capacity | 7000 milliampere hour |
| description of product type | Battery module 7 Ah |
| max. ambient temperature | 50 degree_Celsius |
| battery pack present | Yes |
| min. ambient temperature | -15 degree_Celsius |
| Overall Height | 5.28 in |
| Includes Battery | Battery Included |
| Power Rating - Real | 42 W |
| Frequency | 50/60 Hz |
| Power Cord Length | Not Applicable |
| Overall Width | 7.31 in |
| Overall Depth | 4.33 in |
| Data Line Protection | No Data Line Surge Protection |
| Operating Temperature - Maximum | 122 deg F |
| Battery Chemistry | Not Applicable |
| Number of Outlets - Surge Only | 0 |
| Receptacle Configuration | Hardwired |
| Operating Temperature - Minimum | 5 deg F |
| Automatic Voltage Regulation | No Automatic Voltage Regulation |
| Package Quantity | 1 |
