VPLB1003TPK12AA 6ES71936BP000DA0
| Depth | 35 millimetre |
|---|---|
| Width | 15 millimetre |
| Height | 117 millimetre |
| Integrated current supply present | No |
| Rack-assembly possible | No |
| plug-in modules, central modules present | No |
| min. input voltage with DC | 19 V |
| min. output voltage with DC | 19.2 V |
| Bearing track assembly possible | Yes |
| Input voltage, type | DC |
| Manufacturer product family | ET 200SP |
| plug-in modules, analog E/A present | Yes |
| max. output voltage with DC | 28.8 V |
| Output voltage type | DC |
| Explosion protection categories for gases | ATEX gas-ex-protection, Cat. 3 |
| max. input voltage with DC | 28.8 V |
| Manufacturer product root | BaseUnit |
| pluggable module (communication module) present | Yes |
| plug-in modules, function and technology modules present | Yes |
| Front installation possible | No |
| plug-in modules, other present | No |
| wall mounting/direct mounting possible | No |
| System components present | Yes |
| description of product type | BU type A0 |
| Number of slots | 1 |
| plug-in modules, digital E/A present | Yes |
| Package Quantity | 1 |
