DC Power Supply, 20/72V DC, 48V DC, 30W, 0.6A, DIN Rail/Chassis
| Item | DC Power Supply |
|---|---|
| Input Voltage | 20/72V DC |
| Output Voltage | 48V DC |
| Power Rating | 30 W |
| Output Amps | 0.6 A |
| Mounting | DIN Rail/Chassis |
| Case Material | Metal Case |
| Phase - Electrical | Single |
| Style | Switching |
| Height | 4.51 in |
| Width | 2.55 in |
| Depth | 1.29 in |
| Hz | 50/60 Hz |
| Standards | CE, cRUus, cULus |
| Features | Rugged, Encapsulated Design To Resist Environment, Terminations Are Also Easy To Access And Simple To Wire, With High Reliability And Wide Input Range, These Units Can Operate Through The Most Difficult Factory-Floor Conditions Around The Globe |
| Output Noise | Less than 3 mV |
| Hold Up Time | Greater than 10 msec |
| Series | SCD |
| Peak Amps | 0.78 |
| IP Rating | IP20 |
| Status Indicator | Green LED |
| Operating Temp. Range | -25 to 60 deg C |
| Output Power | 30 W |
| Wire Connection Type | Terminals |
| Housing Material | Metal |
| Operating Temperature - Maximum | 149 deg F |
| NEMA Enclosure Rating | 1 |
| Operating Temperature - Minimum | -13 deg F |
| Mean Time Between Failures (MTBF) | 800,000 hr |
| Special Features | Galvanic Isolation |
| Manufacturer Warranty | 5 yr (Limited) |
| Current - Peak | 0.78 A |
| Output Power - Rated | 30 W |
| Current - Output | 0.6 A |
| Package Quantity | 1 |
