Surge Protection Device, 1 Phase, 240V, 2 Poles, 2 Wires
| Item | Surge Protection Device |
|---|---|
| Mounting Style | DIN Rail |
| Phase | 1 |
| Voltage | 240 V |
| Number of Poles | 2 |
| Voltage Protection Rating | 1200V (L-G), 800V (L-L) |
| Number of Wires | 2 Wires |
| Modes of Protection | L-G, L-N, N-G, L-L |
| Max. Surge Current Per Mode | 30 kA |
| Max. Surge Current per Phase | 30 kA |
| Nominal Discharge Current | 5 A |
| Short Circuit Current Rating | 5 kA |
| Modular | Yes |
| Filtering | Yes |
| Max. Continuing Operating Voltage | 275V AC |
| IP Rating | IP20 |
| Enclosure Material | Metal |
| Length | 4.88 in |
| Depth | 4.56 in |
| Width | 2.56 in |
| Wire Gauge | 22 AWG |
| Includes | LED Status Indicator |
| Standards | CE, cULus Listed, RoHS, Type 4, UL Listed |
| Green Certification or Other Recognition | ENERGY STAR |
| Green Environmental Attribute | Does not Contain Reproductive or Developmental Toxins (as Per State of CA List), Endocrine Disrupters (as Per European Union Priority For Research List), Asthmagens (as Per AOEC List), Carcinogens (as Per IARC 1-2A-2B Lists) |
| Noise Attenuation | Common: 60dB @ 5 MHz to 50 MHz, Normal: 90dB @ 100kHz to 50 MHz |
| Modular / Nonmodular | Modular |
| Amps | 5 |
| Min. Operating Temp. | -40 deg F |
| Max. Operating Temp. | 122 deg F |
| System Connection | Series |
| UL SPD Type | Type 4 |
| Includes Surge Counter | No |
| Status Indicator | LED Light |
| Single-Phase 120 and 240 Vac Model Amperage | 3.0, 5.0, 10.0, 20.0 |
| Peak Surge Current Capability: Per Phase | 19,500 A |
| Load Surge Current Rating: 10 sec | 2 x Nominal |
| Frequency Response: Normal (F-R) 100 kHz to 50 MHz | 90 dB Max |
| Transient Reduction Typical Category A Ringwave | < 60 V Peak |
| Peak Surge Current Capability: Line to Ground | 6,500 Amps |
| Load Surge Current Rating: 1 sec | 3 x Nominal |
| Frequency Response: Common (F-R) 5 MHz to 50 MHz | 60 dB Max |
| Peak Surge Current Capability: Neutral to Ground | 6,500 Amps |
| Hertz | 47-63 Hz |
| Transient Reduction Typical Category B Ringwave | < 100 V Peak UL 1449 |
| Operating Temperature | -40°C to +50°C |
| Peak Surge Current Capability: Line to Neutral | 13,000 A |
| Load Surge Current Rating: 10 msec | 5 x Nominal |
| Package Quantity | 1 |
