In-Ceiling Speaker, Black, 20 Max. Wattage
| Item | In-Ceiling Speaker |
|---|---|
| Type | In Ceiling |
| Standards | CE Compliant, RoHS, UL1480A, UL2043 |
| Indoor/Outdoor | Indoor |
| Enclosure Material | Plastic, Metal |
| Enclosure Color | Black |
| Includes | Conduit Clamp, Grille, Paint Mask, Tile Bridge or Pre-Construction Bracket, Wire Nuts |
| Sensitivity (dB) | 85 |
| Overall Length (In.) | 8 |
| Overall Height (In.) | 9 |
| Weight (Lbs.) | 4 |
| Tweeter Composition | Paper |
| Woofer Dia. (In.) | 3 |
| Woofer Composition | Polypropylene, Butyl |
| Max. Wattage | 20 W |
| Tweeter Dia. (In.) | 1 |
| Impedance (Ohms) | 8 |
| Depth | 0.6 in |
| Overall Width (In.) | 8 |
| Power Taps @ 75V | 10 |
| Frequency Response | 190Hz to 12KHz |
| Transformer Settings | 25V/70V/100V |
| Watt (RMS) | 20 |
| Power Taps @ 25V | 1 |
| Application | Indoor/Outdoor |
| Overall Height | 4-1/4 in |
| Overall Width | 6-1/4 in |
| Number of Channels | 1 |
| Output Wattage - Peak | 40 W |
| Enclosure Style | Backcan |
| Transformer Taps @ 25V | 1.3 W |
| Woofer Diameter | 3 in |
| Frequency Response - Minimum | 115 Hz |
| Tweeter Material | Paper |
| Overall Depth | 6-1/4 in |
| Mid-Range Material | Not Applicable |
| Dispersion - Horizontal | Not Applicable |
| Housing Color | Black |
| For Hazardous Location | Not Applicable |
| Power Style | Passive |
| Impedance | 8 ohms |
| Includes Transformer | Transformer Included |
| Dispersion - Vertical | Not Applicable |
| Dispersion - Conical | 45 deg |
| Driver Configuration | 1-Way |
| Mounting Style | Flush Mount |
| Frequency Response - Maximum | 22 kHz |
| Sensitivity | 85 dB |
| Power Voltage | Not Applicable |
| For Location | Indoor |
| Transformer Taps @ Low Voltage | 8 ohms |
| IP Rating | IP54 |
| Mid-Range Diameter | Not Applicable |
| Transformer Taps @ 70V | 10 W |
| Tweeter Diameter | 1 in |
| Compatible Input Voltage | 25V, 70V, 100V |
| Output Wattage - RMS | 20 W |
| Housing Material | ABS Glass Fiber |
| Woofer Material | Polypropylene, Butyl |
| Includes Mounting Hardware | Mounting Hardware Included |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
