Extension Spring, Carbon Steel, PK2
| Type | High Precision |
|---|---|
| Material | Music Wire |
| Overall Length | 290 mm |
| Outside Dia. | 3.5 mm |
| Wire Dia. | 0.5 mm |
| Spring Rate (Lbs./In.) | 0.05 N/mm |
| Load (Lbs.) | 2.7 |
| Item | Extension Spring |
| Initial Tension (Lbs.) | 0.34 |
| Finish | Oil |
| Meets/Exceeds | AMS-5112, DIN-17223; JIS-G4314 |
| End Type | Full Twist Loop |
| Deflection @ Load | 210 mm |
| Standards | ASTM A228, EN 10270-1, JIS G3522 SWP - A/B |
| Outside Diameter | 3.5 mm |
| Product Type | Extension Spring |
| Initial Tension | 0.34 lbf |
| Free Length | 290 mm |
| System of Measurement | Metric |
| Spring Rate | 0.05 N/mm |
| Wire Diameter | 0.5 mm |
| Hook Configuration | No Hook |
| Extended Length | 500 mm |
| Country of Origin (subject to change) | China |
| Package Quantity | 2 |
