Thermal Magnetic Trip, 18 kA at 480 VAC Breaking Capacity, 3/0 AWG, 86mm Deep x 191mm High x 104mm Wide
| Circuit Breaker Type | Molded Case |
|---|---|
| Amperage | 200 |
| Voltage | 480V AC |
| Wire Size (AWG) | 3/0 |
| Number Of Poles | 3 |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Bus Bar |
| Mount Type | Unit |
| Overall Width (mm) | 104.00 |
| Overall Width (Decimal Inch - 4 Decimals) | 4.1 |
| Overall Height (Decimal Inch) | 191 |
| Reset Actuator Type | Toggle Switch |
| Standards | UL Listed; CCC; Federal Specification W-C 375 b/Gen; HACR; CSA Certified |
| UNSPSC Code | 39121603 |
| Country of Origin | Mexico |
| MSC Number | MSC# 56749062 |
