Contactor de propósito definido de 208/240VCA sin inversión, de 2 polos y 75 amperios.
| Full Load Amps-Inductive | 75 A |
|---|---|
| Item | Definite Purpose Magnetic Contactor |
| Action | Non-Reversing |
| Full Load Amps-Resistive | 94 A |
| Number of Poles | 2 |
| Coil Volts | 208/240V AC |
| Reversing | No |
| HP @ 1 Phase - 230V | 15 |
| HP @ 1 Phase - 120V | 5 hp |
| Height | 5.2 in |
| HP @ 1 Phase - 240V | 15 hp |
| Width | 3.39 in |
| Depth | 4.37 in |
| Enclosure NEMA Rating | No Enclosure |
| Standards | CSA, RoHS, UL Listed |
| Includes | Quick Connect Terminal |
| Hz | 50/60 |
| Enclosure Type | Open |
| Series | 8910 Series Type DPA |
| Phase | Single |
| Horsepower @ Three Phase - 600V AC | 50 HP |
| NEMA Enclosure Rating | No Enclosure |
| Mounting Hole Distance - Width | 2.87 in |
| Maximum Voltage Rating | 600 V AC |
| Locked Rotor Load | 300 A @ 575V AC, 375 A @ 460V AC, 450 A @ 277V AC |
| Includes Shunt | Not Applicable |
| Overall Depth | 4.37 in |
| Frequency | 50/60 Hz |
| Mounting Hole Diameter | 0.2 in |
| Number of Normally Open Main Contacts | 2 |
| Full Load Current - Inductive | 75 A |
| Tungsten Lighting Current Rating | Not Applicable |
| Frame Size | Not Applicable |
| Reversing Capability | Non-Reversing |
| NEMA Enclosure Material | Not Applicable |
| Fluorescent Lighting Current Rating | Not Applicable |
| Overall Width | 5 in |
| Contactor Style | HVACR Definite Purpose Contactor |
| Terminal Connection Type | Terminals, Box Lugs |
| Horsepower @ Single Phase - 120V AC | 5 HP |
| Full Load Current - Resistive | 94 A |
| LED Lighting Current Rating | Not Applicable |
| Coil Voltage | 220/208-240V AC |
| Mounting Hole Distance - Height | 4.63 in |
| Horsepower @ Single Phase - 240V AC | 15 HP |
| Overall Height | 5.12 in |
| Package Quantity | 1 |
