Buck Boost Transformer, 750 VA, NEMA 3R, 115°C, 16/32V AC, 120/240V AC
| Item | Buck Boost Transformer |
|---|---|
| Input Voltage - Transformer | 120/240V AC |
| Mounting - Transformer | Wall |
| Hz - Electrical | 60 |
| IP Rating | IP54 |
| Outdoor Rated - Transformer | Yes |
| Color | Gray |
| Manufacturers Warranty Length | 18 mo |
| Temp. Rise | 115 deg C |
| Enclosure Finish | Powder Coated |
| Depth | 4.7 in |
| Enclosure Rating | NEMA 3R |
| Phase - Electrical | 1 |
| Standards | CSA, cULus, RoHS Compliant, UL and cUL Listed (UL 506) |
| VA Rating - Transformer | 750 VA |
| Output Voltage - Transformer | 16/32V AC |
| Knockout Size - Transformer | 1/2 in |
| Width | 6.2 in |
| Height | 6.7 in |
| Insulation Max. Temp. | 180 °C |
| Features | Mercury Free; PVC Free; Green Premium product; Toxic Heavy Metal Free |
| Enclosure Code | 6A |
| Insulation Temperature | 356°F |
| Primary Voltage | 120 x 240 V |
| Includes Knockouts | Knockouts Included |
| Insulation Temperature Rating | 356 deg F |
| Package Quantity | 1 |
