Circuit Breaker Enclosure, J250, 3 Spaces, 250A, Main Circuit Breaker
| CAD Available | Yes |
|---|---|
| Item | Circuit Breaker Enclosure |
| Main Circuit Breaker or Main Lug | Main Circuit Breaker |
| Number of Spaces | 3 |
| Amps | 250A |
| Height | 32.26 in |
| Width | 9.72 in |
| Depth | 7.94 in |
| Series | J250 |
| Included Enclosure Cover | Surface Cover |
| Recommended Surface Cover | Included |
| Enclosure Material | Steel |
| Enclosure NEMA Rating | NEMA 3R, NEMA 5, NEMA 12 |
| Finish | Powder Coated |
| Mounting Style | Surface |
| Color | Gray |
| For Use With | Square D H and J-Frame Circuit Breakers |
| Material | Steel |
| Length | 32.26 in |
| NEMA Rating | 12, 3R, 5 |
| Exterior Width | 9.72 in |
| Exterior Height | 32.26 in |
| Recommended Neutral Assmebly Kit | 2CR90, 2JXG4 |
| Exterior Depth | 7.94 in |
| Min. Operating Temp. | 32 deg F |
| Location | Outdoor |
| Conduit Provision | 1, 1 1/4, 1 1/2, 2, 2 1/2, 3 |
| Recommended Service Ground Kit | 48N057, Mfr. No. PKOGTH150 |
| Cover Closure Method | Latch |
| Max. Operating Temp. | 140 deg F |
| Cover Attachment Style | Side Hinge |
| Product Destination | circuit breaker H-Frame 15-250 A || circuit breaker J-Frame 15-250 A |
| Breaker Compatibility | Circuit breaker H-Frame 15 to 250 A; Circuit breaker J-Frame 15 to 250 A |
| Package Quantity | 1 |
