Circuit Breaker, FAL Series, 50A, 3 Pole, 240V AC, Not Rated
| Item | Circuit Breaker |
|---|---|
| Series | FAL |
| Amps | 50A |
| Number of Poles | 3 |
| AC Voltage Rating | 240V AC |
| Circuit Breaker Type | Standard |
| Phase | 3 |
| Circuit Breaker Mounting Style | Unit Mount |
| Max. AIR Rating | Not Rated |
| Trip Type | Thermal Magnetic |
| Instantaneous Trip | Fixed |
| Terminal Connection | Lug |
| Phase Connection | ABC |
| Frame Size | 100A, FA |
| Width | 4-1/2 in |
| Depth | 4.13 in |
| Height | 6.4 in |
| DC Voltage Rating | 250V DC |
| Standards | UL Listed, CSA Certified, CE Marked, IEC, Federal Specification W-C-375B/GEN |
| High Amp Trip Setting | 850 A |
| Max. Wire Size | 1/0 AWG |
| Low Amp Trip Setting | 400 A |
| Min. Wire Size | 14 AWG (Cu), 12 AWG (Al) |
| Mounting | Free Standing |
| Package Quantity | 1 |
