Contactor, Propósito Definido, 40A, 3 polos, 25 HP a 575 VAC, 3 fases, bobina de 24/24 VAC 50/60 Hz, con 2 tornillos de montaje.
| Item | Definite Purpose Magnetic Contactor |
|---|---|
| Full Load Amps-Inductive | 40 A |
| Full Load Amps | 40 |
| Number of Poles | 3 |
| Coil Volts | 600VAC |
| Standards | UL Recognized || CSA |
| Phase | 3 phase |
| Maximum Horse Power Rating | 3 hp 115 V AC, 1 phase; 7.5 hp 230 V AC, 1 phase; 10 hp 230 V AC, 3 phase; 20 hp 460 V AC, 3 phase; 25 hp 575 V AC, 3 phase |
| Pole Contact Composition | 3 NO |
| Product Or Component Type | Definite Purpose Contactor |
| Rated Operational Voltage | 600 V AC |
| Control Circuit Voltage | 24 V AC 50/60 Hz |
| Electrical Connection | Box lugs; Quick connect terminals |
| Locked Rotor Rated Current | 240 A 277 V AC; 200 A 460 V AC; 160 A 575 V AC |
| Provided Equipment | Mounting Hardware |
| Product Certifications | UL Recognized; CSA |
| Poles Description | 3P |
| Range of Product | DPA |
| Package Quantity | 1 |
