Control Transformer, 3 kVA, Not Rated, 55°C, 120V AC, 240/480V AC
| Item | Control Transformer |
|---|---|
| Input Voltage - Transformer | 240/480V AC |
| Mounting - Transformer | Foot |
| Hz - Electrical | 60 |
| Width | 9 in |
| Temp. Rise | 55 deg C |
| Height | 7-1/2 in |
| Standards | CE, CSA, REACH, RoHS, UL Listed |
| Protective Device | None |
| Enclosure Finish | Epoxy Resin Varnish |
| Phase - Electrical | 1 |
| Manufacturers Warranty Length | 18 mo |
| Fused | No |
| Enclosure Style - Transformer | Open |
| Output Voltage - Transformer | 120V AC |
| VA Rating - Transformer | 3 kVA |
| Depth | 9.44 in |
| Includes | Not Applicable |
| Green Environmental Attribute | Mercury Free; Pvc Free |
| Enclosure Type | Open |
| Insulation Max. Temp. | 130 °C |
| Secondary Connection | Screw clamp terminals |
| Primary Connection | Screw clamp terminals |
| Enclosure Rating | Not Rated |
| Package Quantity | 1 |
