Interruptor de seguridad fusible, de servicio general, 240V CA, 3PST, 600 A, NEMA 1.
| Item | Safety Switch |
|---|---|
| Protection Method | Fusible |
| Duty | General |
| Voltage | 240V AC |
| Phase | 3 |
| HP | 75 HP @ 240 V AC |
| NEMA Enclosure Type | 1 |
| IP Rating | 20 |
| Number of Wires | 4 |
| Number of Poles | 3 |
| Contact Form | 3PST |
| Amps AC | 600 A |
| Metallic / Non-Metallic | Metallic |
| Material of Construction | Steel |
| Depth | 8.9 in |
| Width | 24.9 in |
| Height | 49.1 in |
| Fusible / Nonfusible | Fusible |
| Standards | UL listed |
| Fuse Kit (Class R) | Mfr. No. DRK600 |
| For Use With | Class H, J, K, R Fuse |
| Fuse Type | Class H, K, R or J |
| Gauge/Conductor | 4 AWG to 500 kcmil |
| Neutral Assembly Included | Yes |
| Weight | 53 kg |
| Mounting | Surface |
| Electrical Connection | Lugs |
| Features | Mercury Free, PVC Free |
| Enclosure Type | Enclosed |
| Mounting Style | Surface Mount |
| Compatible with Manufacturer Model Number | DRK600 |
| For Fuse Class | Class H, Class J, Class K, Class R |
| Horsepower @ 240V AC | 75 HP |
| Includes Neutral Assembly | Yes |
| Current Rating | 600 A |
| Housing Material | Steel |
| Environment | Indoor |
| NEMA Enclosure Rating | 1 |
| Compatible Manufacturer Part Number | DRK600 |
| Compatible with Manufacturer Part Number | DRK600 |
| Compatible with Manufacturer Model Number [NEW] | DRK600 |
| Compatible Manufacturer Model Number | DRK600 |
| For Use with Mfr. Model Number | DRK600 |
| Package Quantity | 1 |
