Interruptor de seguridad fusible, deber general, 240V CA/CC, 2PST, 400 A, NEMA 1.
| Item | Safety Switch |
|---|---|
| Protection Method | Fusible |
| Duty | General |
| Voltage | 240V AC/DC |
| Phase | 1 |
| NEMA Enclosure Type | 1 |
| IP Rating | 20 |
| Number of Wires | 3 |
| Number of Poles | 2 |
| Contact Form | 2PST |
| Amps AC | 400 A |
| Metallic / Non-Metallic | Metallic |
| Material of Construction | Steel |
| Width | 24.9 in |
| Depth | 8.9 in |
| For Use With | Class R Fuse |
| Fuse Kit (Class R) | Mfr. No. DRK40 |
| Height | 45.1 in |
| Standards | UL listed |
| Fusible / Nonfusible | Fusible |
| Fuse Type | Class H, K, R or J |
| Gauge/Conductor | 1/0 AWG to 600 kcmil, 1/0 AWG to 300 kcmil |
| Features | Mercury Free, PVC Free |
| Enclosure Type | Enclosed |
| Neutral Assembly Included | Yes |
| Mounting | Surface |
| Weight | 52 kg |
| Electrical Connection | Lugs |
| Current Rating | 400 A |
| Horsepower @ 480V AC | 400 HP |
| Compatible with Manufacturer Model Number | DRK40 |
| Horsepower @ 600V AC | 500 HP |
| Environment | Indoor |
| Mounting Style | Surface Mount |
| For Fuse Class | Class H, Class J, Class K, Class R |
| Horsepower @ 240V AC | 200 HP |
| Housing Material | Steel |
| Includes Neutral Assembly | Yes |
| NEMA Enclosure Rating | 1 |
| Compatible Manufacturer Part Number | DRK40 |
| Compatible with Manufacturer Part Number | DRK40 |
| Compatible with Manufacturer Model Number [NEW] | DRK40 |
| Compatible Manufacturer Model Number | DRK40 |
| For Use with Mfr. Model Number | DRK40 |
| Package Quantity | 1 |
