General Purpose Transformer, 750 VA, NEMA 3R, 115°C, 120/240V AC, 600V AC
| Item | General Purpose Transformer |
|---|---|
| Input Voltage - Transformer | 600V AC |
| Mounting - Transformer | Wall |
| Hz - Electrical | 60 |
| IP Rating | IP54 |
| Outdoor Rated - Transformer | Yes |
| Winding Material | Copper |
| Color | Gray |
| Height | 6.9 in |
| Manufacturers Warranty Length | 1 yr |
| Temp. Rise | 115 deg C |
| Width | 8.2 in |
| Voltage Function - Transformer | Step Down |
| Output Voltage - Transformer | 120/240V AC |
| VA Rating - Transformer | 750 VA |
| Enclosure Rating | NEMA 3R |
| Enclosure Finish | Paint |
| Enclosure Material | Steel |
| Knockout Size - Transformer | 1/2 in |
| Winding Material - Transformer | Copper |
| Standards | CSA Certified, cULus, REACH Regulation, RoHS, UL Listed |
| Depth | 8.8 in |
| Phase - Electrical | 1 |
| Includes | Not Applicable |
| Insulation Max. Temp. | 180 °C |
| Includes Knockouts | Knockouts Included |
| Sound Level | 37 dB |
| Package Quantity | 1 |
