The Square D HOM120AFI is a 1 Pole molded case ground fault circuit breaker with a current rating of 15 Amps and a voltage rating of 120VAC. It has an interrupting rating of 10kAIC at 120VAC. The HOM120AFI has a plug-in connection type and includes long time and instantaneous trip functions.
| Brand | Square D |
|---|---|
| Series | Homeline |
| Amperage | 15 |
| Voltage | 120VAC |
| Poles | 1 |
| Phase | 1 |
| Mounting Type | Plug-On |
| Approval | UL, CSA |
| Interrupting Rating | 10kAIC at 120VAC |
| Frame Type | HOM |
| Connection Type | Plug-In |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous Trip |
| Terminal Connection | Screw Clamp |
| Length (in) | 2.98 |
| Width (in) | 1 |
| Height (in) | 3.13 |
| Wire Gauge | 1x AWG 14 to AWG 10, Al/Cu |
| For Use With | Homeline Load Center |
| Standards | RoHS, REACh, HACR |
| Temperature Rating | 40 °C |
| Circuit Breaker Type | GFCI |
| Breaker Feature | Mercury Free |
| Actuator Type | Paddle |
| Max Wire Size | 10 AWG |
| Min Wire Size | 14 AWG |
| Mpn | HOM115GFI |
| Upc | 785901065364 |
| Gtin | 785901065364 |
