Bobina magnética, IEC, 480VCA, 60 Hz.
| Item | Replacement Coil |
|---|---|
| Coil Volts | 480 V AC |
| VA Rating | 220 |
| For Use With | LC1D40, 50, 65 and 80 Series Contactors |
| Hz | 60 |
| Contactor Type | IEC |
| Product Compatibility | LC1D80 || LC1D95 |
| Control Circuit Type | AC 60 Hz |
| Hold-In Power Consumption In Va | 22-22 VA 60 Hz 0.3 20 °C) |
| Maximum Operating Rate | 3600 cyc/h 60 °C |
| Mechanical Durability | 10 Mcycles |
| Device Short Name | LX1D6 |
| Coil Technology | without built-in suppressor module |
| Inductance Of Closed Circuit | 23 H |
| Ambient Air Temperature For Operation | -5-60 °C |
| Control Circuit Voltage Limits | drop-out 0.3 to 0.6 Uc 50/60 Hz 55 °C) || operational 0.8 to 1.1 Uc 50 Hz 55 °C) || operational 0.85 to 1.1 Uc 60 Hz 55 °C) |
| [Uc] Control Circuit Voltage | 480 V AC 60 Hz |
| Average Resistance | 480 Ohm 20 °C |
| Range | TeSys |
| Heat Dissipation | 6-10 W 50/60 Hz |
| Product Or Component Type | contactor coil |
| Inrush Power In Va | 220-220 VA 60 Hz 0.75 20 °C) |
| Contactor Style | IEC |
| Compatible with Series | LC1D80 Contactors, LC1D95 Contactors, TeSys Deca |
| Frequency | 60 Hz |
| Coil Voltage | 480V AC |
| Coil Power | 220 VA |
| NEMA Size | Not Applicable |
| Package Quantity | 1 |
