Arrancador de motor manual, 13 a 18A, 600V.
| Operator | Switch |
|---|---|
| Type | F |
| Enclosure NEMA Rating | No Enclosure |
| Number of Required Thermals | 1 |
| Depth | 1.59 in |
| Amps AC | 16 A |
| Height | 4.12 in |
| Item | Manual Motor Starter |
| Width | 1.69 in |
| Number of Poles | 1 |
| Max. Voltage | 600V AC |
| HP @ 1 Phase - 120V | 1 hp |
| Pilot Light | No |
| Description/Special Features | Class 10 Ambient-Compensated Thermal Overload Relay |
| HP @ 1 Phase - 230V | 1 hp |
| Standards | CSA LR25490, E42243 CCN NLRV2, UL Listed |
| Number of Gangs | 1 |
| Phase Loss Sensitivity | No |
| Product Certifications | UL recognized E42243 CCN NLRV2 || CSA LR25490 class 3211 05 |
| Electrical Connection | Screw Clamp Terminals |
| Phase | Single |
| Thermal Overload Type | melting alloy |
| Reset | Manual |
| Nema Degree Of Protection | not rated (open device) |
| Cable Entry | without |
| Awg Gauge | AWG 14...AWG 12 copper |
| Line Rated Current | 16 A |
| Maximum Horse Power Rating | 1 hp 115 V AC || 1 hp 230 V AC || 1 hp 277 V AC |
| [Ue] Rated Operational Voltage | 277 V AC |
| Product Or Component Type | Single Unit Manual Starter |
| Poles Description | 1P |
| Local Signalling | no indicator |
| Motor Starter Type | non reversing |
| Control Type | toggle switch |
| Overall Width | 1.69 in |
| Maximum Voltage Rating | 277 V AC |
| Overall Depth | 2.22 in |
| Horsepower @ Single Phase - 240V AC | 1 HP |
| Status Indicator | No Indicator |
| Series | Class 2510 F Series |
| Starter Style | NEMA |
| Current AC | 16 A |
| Minimum Overload Relay Current Setting | Not Applicable |
| Maximum Overload Relay Current Setting | Not Applicable |
| Overall Height | 4.13 in |
| Mounting Hole Distance - Height | 3.28 in |
| Horsepower @ Single Phase - 120V AC | 1 HP |
| Overload Protection Type | Thermal |
| Terminal Connection Type | Screw Terminals |
| NEMA Enclosure Rating | No Enclosure |
| Includes Pilot Light | No |
| Number Of Phases | 1 phase |
| Wire Gauge | AWG 14 to AWG 12 copper |
| Horsepower Rating | 1 hp 115 V AC; 1 hp 230 V AC; 1 hp 277 V AC |
| Package Quantity | 1 |
