Inicio de motor manual, 13 a 18A, 600V
| Operator | Push Button |
|---|---|
| NEMA Size | M-1 |
| Type | M |
| Enclosure NEMA Rating | 4, 4X |
| Number of Required Thermals | 1 |
| Depth | 5-3/4 in |
| Frame Size | Not Applicable |
| Amps AC | 27 A |
| Height | 10-3/4 in |
| Width | 5-3/4 in |
| Item | Manual Motor Starter |
| Starter Type | Non reversing |
| Number of Poles | 2 |
| Max. Voltage | 600V AC |
| HP @ 1 Phase - 120V | 2 hp |
| Pilot Light | No |
| Standards | CSA LR60905, E42243 CCN NLRV, UL Listed |
| HP @ 1 Phase - 230V | 3 hp |
| Description/Special Features | Melting Alloy Thermal Overload Relays |
| Thermal Unit Code | K2 |
| Phase Loss Sensitivity | No |
| Overload Protection Type | Thermal |
| Overall Depth | 5.76 in |
| NEMA Enclosure Rating | 4X |
| Starter Style | NEMA |
| Horsepower @ Single Phase - 240V AC | 3 HP |
| Overall Width | 5.78 in |
| Phase | Single |
| Maximum Voltage Rating | 600 V AC |
| Current AC | 27 A |
| IP Rating | Not Applicable |
| Maximum Overload Relay Current Setting | Not Applicable |
| Series | Class 2510 M Series |
| Overall Height | 10.92 in |
| Status Indicator | No Indicator |
| Includes Pilot Light | No |
| Minimum Overload Relay Current Setting | Not Applicable |
| Terminal Connection Type | Screw Clamp Terminals |
| Horsepower @ Single Phase - 120V AC | 2 HP |
| Overload Relay Type | Melting alloy |
| Voltage Rating | 600 V AC |
| Control Unit | Push-button |
| Electrical Connection | pressure wire clamp |
| Auxiliary Contacts | Without |
| Wire Gauge | AWG 14 to AWG 8 copper |
| Certifications | CSA LR60905 class 3211 05; UL listed file E42243 CCN NLRV |
| Horsepower Rating | 2 hp 115 V AC, 1 phase; 3 hp 230 V AC, 1 phase |
| Package Quantity | 1 |
