Miniature Circuit Breaker, EDB Series, 50A, 2 Pole, 347/600V AC, 25kA at 120V AC
| Item | Miniature Circuit Breaker |
|---|---|
| Series | EDB |
| Amps | 50A |
| Number of Poles | 2 |
| AC Voltage Rating | 347/600V AC |
| Circuit Breaker Type | Standard |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Bolt On |
| Max. AIR Rating | 25kA at 120V AC |
| Trip Type | Thermal Magnetic |
| Terminal Connection | Lug |
| Frame Size | 125A, EDB |
| Width | 1.96 in |
| Depth | 4.05 in |
| Height | 5.66 in |
| DC Voltage Rating | Not Rated |
| Standards | cULus |
| Application | HACR rated Applications |
| For Use With | NF Panelboard |
| Features | Mercury Free |
| Max. Wire Size | 2/0 AWG (Cu/Al) |
| Interrupt Rating | 14 kA at 600Y/347V AC |
| Min. Wire Size | 12 AWG (Al), 14 AWG (Cu) |
| High Amp Trip Setting | 1,800 A |
| Ambient Air Temperature For Operation | 104°F (40°C) |
| Breaking Capacity Code | D |
| Local Signalling | Trip indicator |
| Maximum Operating Voltage | 600Y/347 V AC |
| Tightening Torque | 34.52 lbf.in (3.9 N.m) 0.00 to 0.01 in² (2.5 to 6 mm²) (AWG 14 to AWG 10); 49.56 lbf.in (5.6 N.m) 0.02 to 0.11 in² (10 to 70 mm²) (AWG 8 to AWG 2/0) |
| Circuit Breaker Application | HACR rated |
| Holding Current | 630 A |
| Module Type | E-Frame |
| Protection Type | Overload; Short-circuit |
| Breaking Capacity | 14 kA 600Y/347 V AC |
| AWG Gauge | AWG 12 to AWG 2/0 aluminium; AWG 14 to AWG 2/0 copper |
| Package Quantity | 1 |
