Molded Case Circuit Breaker, BDA Series, 45 A, 2 Pole, 525V AC, 25kA at 277/408V AC
| Item | Molded Case Circuit Breaker |
|---|---|
| Series | BDA |
| Amps | 45 A |
| Number of Poles | 2 |
| AC Voltage Rating | 525V AC |
| Circuit Breaker Type | Standard |
| Phase | Single |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | I-Line |
| Max. AIR Rating | 25kA at 277/408V AC |
| Trip Type | Thermal Magnetic |
| Instantaneous Trip | Fixed |
| Terminal Connection | Al Mechanical Lug, OFF End, I-Line ON End |
| Phase Connection | AB |
| Frame Size | 125A, BD |
| Width | 2.13 in |
| Depth | 3-1/2 in |
| Height | 5.39 in |
| DC Voltage Rating | Not Rated |
| Min. Wire Size | 14 AWG |
| For Use With | Electrical Distribution Equipment, Industrial Control Panels |
| Max. Wire Size | 2 AWG |
| Mounting | I-Line |
| Standards | CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489 |
| Min. Operating Temp. | -13 deg F |
| Max. Operating Temp. | 158 deg F |
| Package Quantity | 1 |
