Molded Case Circuit Breaker, LA Series, 300A, 2 Pole, 600V AC, 42kA at 240V AC
| Item | Molded Case Circuit Breaker |
|---|---|
| Series | LA |
| Amps | 300A |
| Number of Poles | 2 |
| AC Voltage Rating | 600V AC |
| Circuit Breaker Type | Standard |
| Phase | 1 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | I-Line, Plug-On |
| Max. AIR Rating | 42kA at 240V AC |
| Trip Type | Thermal Magnetic |
| Instantaneous Trip | Adjustable |
| Terminal Connection | Lug, I-Line |
| Phase Connection | BC |
| Frame Size | 400A, LA |
| Width | 6 in |
| Depth | 5.8 in |
| Height | 11 in |
| DC Voltage Rating | 250V DC |
| Min. Wire Size | 1 AWG (Al) |
| Low Amp Trip Setting | 1,500 A |
| High Amp Trip Setting | 3,000 A |
| For Use With | I Line Panelboards |
| Max. Wire Size | 250 MCM (Al), 600 MCM (Cu) |
| Standards | CSA Certified, UL Listed |
| Features | Mercury Free; PVC Free |
| Application | HACR rated Applications |
| Mounting | Plug In Panelboard |
| Wiring Configuration | 4-wire |
| Tightening Torque | 115.06 lbf.in (13 N.m) 0.07 to 0.47 in² (42 to 304 mm²) (AWG 1 to 600 kcmil); 115.06 lbf.in (13 N.m) 0.07 to 0.20 in² (42 to 127 mm²) (AWG 1 to 250 kcmil) |
| Magnetic Hold Current | 1,500 A |
| Terminal Identifier | AL400LA |
| Magnetic Tripping Current | 3,000 A |
| Circuit Breaker Application | HACR rated |
| Breaking Capacity Code | A |
| Certifications | UL Listed; CSA |
| Package Quantity | 1 |
