Molded Case Circuit Breaker, MJ Series, 400 A, 2 Pole, 600V AC, 25kA at 600V AC
| Item | Molded Case Circuit Breaker |
|---|---|
| Series | MJ |
| Amps | 400 A |
| Number of Poles | 2 |
| AC Voltage Rating | 600V AC |
| Circuit Breaker Type | Standard |
| Phase | Single |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Panel Mount |
| Max. AIR Rating | 25kA at 600V AC |
| Trip Type | Electronic |
| Instantaneous Trip | Adjustable |
| Terminal Connection | Box Lug |
| Phase Connection | AC |
| Frame Size | 800A, M |
| Width | 8.3 in |
| Depth | 8.1 in |
| Height | 12.9 in |
| DC Voltage Rating | Not Rated |
| Max. Wire Size | 500 MCM |
| For Use With | I Line Panelboards |
| High Amp Trip Setting | 4,000 A |
| Low Amp Trip Setting | 800 A |
| Standards | BS, CCC, CEI, CSA Certified, Federal Specification W-C-375B/GEN, IEC, NEMA, NMX, UL Listed, UNE, UTE, VDE |
| Mounting | Panel Mount |
| Min. Wire Size | 3/0 AWG |
| Package Quantity | 1 |
