Molded Case Circuit Breaker, Q4 Series, 400A, 3 Pole, 240V AC, 25kA at 120/240V AC
| Item | Molded Case Circuit Breaker |
|---|---|
| Series | Q4 |
| Amps | 400A |
| Number of Poles | 3 |
| AC Voltage Rating | 240V AC |
| Circuit Breaker Type | Standard |
| Phase | 3 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Unit Mount |
| Max. AIR Rating | 25kA at 120/240V AC |
| Trip Type | Thermal Magnetic |
| Instantaneous Trip | Adjustable |
| Terminal Connection | Lug |
| Phase Connection | ABC |
| Frame Size | 400A, Q4 |
| Width | 6 in |
| Depth | 5.84 in |
| Height | 11 in |
| DC Voltage Rating | Not Rated |
| High Amp Trip Setting | 4,000 A |
| Max. Wire Size | 250 MCM, 600 MCM |
| Standards | CSA, IEC, UL Listed |
| For Use With | Busway Plug-In Units, Combination Starters, Industrial Enclosures, Motor Control Centers, Panelboards, Switchboards |
| Min. Wire Size | 1/0 AWG |
| Low Amp Trip Setting | 2,000 A |
| Features | Mercury Free; PVC Free |
| Mounting | Free Standing |
| Package Quantity | 1 |
