Contactor NEMA, Tipo S, no reverso, Tamaño 4, 135A, 1 fase, hasta 100kA, 2 polos, bobina de 480VCA, abierto.
| Item | Contactor |
|---|---|
| Full Load Amps | 135 |
| Action | Non-Reversing |
| Number of Poles | 2 |
| Coil Volts | 600VAC |
| Height | 208.03 mm |
| Width | 152.4 mm |
| Depth | 165.1 mm |
| NEMA Size | 4 |
| Contactor Application | non-reversing |
| Product Certifications | UL listed file E78351 CCN NLDX || CSA |
| Local Signalling | no indicator |
| Control Type | No control units |
| Control Circuit | common control circuit |
| Poles Description | 2P |
| Product Compatibility | circuit-breaker 225 A maximum, SCCR: 100 kA at 480 V AC || fuse J 200 A maximum, SCCR: 100 kA at 600 V AC || fuse T 200 A maximum, SCCR: 100 kA at 600 V AC || fuse RK1 200 A maximum, SCCR: 100 kA at 600 V AC || fuse RK5 200 A maximum, SCCR: 100 kA at 600 V AC |
| [Uc] Control Circuit Voltage | 480 V AC 60 Hz || 440 V AC 50 Hz |
| Nema Degree Of Protection | not rated (open device) |
| Electrical Connection | Screw Clamp Terminals |
| Line Rated Current | 135 A |
| Product Or Component Type | Contactor |
| Phase | 1 phase |
| Rated Power In Hp | not rated |
| Auxiliary Contact Composition | without |
| [Ue] Rated Operational Voltage | 600 V AC |
| Certifications | UL listed file E78351 CCN NLDX; CSA |
| Coil Voltage | 480 V AC 60 Hz; 440 V AC 50 Hz |
| Short Circuit Current Rating | Circuit-breaker 225 A maximum, SCCR: 100 kA at 480 V AC; Fuse J 200 A maximum, SCCR: 100 kA at 600 V AC; Fuse T 200 A maximum, SCCR: 100 kA at 600 V AC; Fuse RK1 200 A maximum, SCCR: 100 kA at 600 V AC; Fuse RK5 200 A maximum, SCCR: 100 kA at 600 V AC |
| Range of Product | 8502S |
| Provided Equipment | fuse not supplied |
| Package Quantity | 1 |
