Interruptor de seguridad no fusible, resistente, 600V AC/DC, 2 polos, 600 A, NEMA 1
| Item | Safety Switch |
|---|---|
| Protection Method | Nonfusible |
| Duty | Heavy |
| Voltage | 600V AC/DC |
| Phase | 1 |
| HP | 50 hp @ 250/600V DC |
| NEMA Enclosure Type | 1 |
| IP Rating | 20 |
| Number of Wires | 2 |
| Number of Poles | 2 |
| Contact Form | 2PST |
| Amps AC | 600 A |
| Metallic / Non-Metallic | Metallic |
| Material of Construction | Steel |
| Height | 50.2 in |
| Fusible / Nonfusible | Nonfusible |
| Depth | 10.1 in |
| Standards | UL listed |
| Width | 27.6 in |
| Mounting | Surface |
| Gauge/Conductor | 3/0 AWG to 500 kcmil |
| Neutral Assembly Included | No |
| Features | Mercury Free, PVC Free |
| Weight | 72.6 kg |
| Electrical Connection | Lugs |
| Housing Material | Steel |
| For Fuse Class | Not Applicable |
| Horsepower @ 240V AC | 200 HP |
| Mounting Style | Surface Mount |
| NEMA Enclosure Rating | 1 |
| Horsepower @ 600V AC | 50 HP |
| Current Rating | 600 A |
| Environment | Indoor |
| Horsepower @ 480V AC | 400 HP |
| Package Quantity | 1 |
