Bloque de distribución de energía, Linergy, 1 poste, 1 línea, 1 carga, 150A Cu, 600V.
| Item | Power Distribution Block 600V 150A |
|---|---|
| Number of Poles | 1 |
| Primary Connections/Pole | 1 |
| Primary Wire Range (AWG) | AWG 18 to AWG 1/0 (Copper) |
| Secondary Connection/Pole | 1 |
| Secondary Wire Range (AWG) | AWG 18 to AWG 1/0 (Copper) |
| Voltage Rating | 600V AC/DC |
| Standards | CE; UL Recognized E60616 CCN XCFR2; CSA File 70361 Class 6228 01 |
| Length | 2.88 in |
| Width | 1.13 in |
| Depth | 1.78 in |
| Material | Phenolic |
| Amps | 150 (Cu Conductor) |
| Mounting | Surface Mount |
| Features | Mercury Free |
| Electrical Connection | Tin plated Copper Lugs |
| Min. Operating Temp. | -40°F |
| Wire Strip Length | 3/4 in (Line), 3/4 in (Load) |
| Max. Operating Temp. | 302°F |
| Short Circuit Current Rating | 65 kA |
| Height | 2.88 in |
| Terminal Tightening Torque | Line lug 50 lbf.in (5.65 N.m) AWG 6 to AWG 1/0 copper; Line lug 40 lbf.in (4.52 N.m) AWG 8 copper; Line lug 35 lbf.in (3.95 N.m) AWG 14 to AWG 10 copper; Load lug 50 lbf.in (5.65 N.m) AWG 6 to AWG 1/0 copper; Load lug 40 lbf.in (4.52 N.m) AWG 8 copper; Load lug 35 lbf.in (3.95 N.m) AWG 14 to AWG 10 copper |
| Ambient Air Temperature For Operation | -40 to 302°F |
| Wire Size | Line 1, AWG 18 to AWG 1/0, copper; Load 1, AWG 18 to AWG 1/0, copper |
| End Barrier | 9080LB21 |
| Terminals Per Pole | 1 line; 1 load |
| Wire Stripping Length | Line: 0.75 in (19.05 mm); Load: 0.75 in (19.05 mm) |
| Current Rating | 150 A copper |
| Block Material | Phenolic: block |
| Line Rated Current | 150-150 A copper |
| Connections - Terminals | line lug 50 lbf.in AWG 6...AWG 1/0 copper, line lug 40 lbf.in AWG 8 copper, line lug 35 lbf.in AWG 14...AWG 10 copper, load lug 50 lbf.in AWG 6...AWG 1/0 copper, load lug 40 lbf.in AWG 8 copper, load lug 35 lbf.in AWG 14...AWG 10 copper |
| Number of Terminals | 1 line, 1 load |
| Range of Product | 9080LB |
| Number of Cables | line 1 , AWG 18...AWG 1/0, copper, load 1 , AWG 18...AWG 1/0, copper |
| [Ics] Rated Service Breaking Capacity | 100 kA UL 508 A |
| Product or Component Type | Power Distribution Block |
| [Ue] Rated Operational Voltage | 600 V AC/DC |
| Package Quantity | 1 |
