Relevador, 240VAC de voltaje en la bobina, 4PDT.
| Item | Relay |
|---|---|
| Coil Volts | 240VAC |
| Contact Form - Relay | 4PDT |
| Mounting - Relay | Socket |
| Contact Material | Silver Tin Oxide |
| Body Height - Relay | 29.4 mm |
| Body Width - Relay | 23.1 mm |
| Body Depth - Relay | 38.9 mm |
| Standards | UL Listed; UL Recognized; CSA; CE |
| Series | Square D 8501R Miniature Series |
| Operating Time | 20 ms - pick-up || 20 ms - drop-out |
| Switching Voltage | 30 V DC, 240 V AC |
| Operating Temp. Range | -40-131°F |
| Pin Shape | spade |
| Status Indicator | No Indicator |
| Package Quantity | 1 |
