Relevador, 250VCA Voltios de Bobina, 4PDT
| Item | Relay |
|---|---|
| Coil Volts | 250VAC |
| Contact Form - Relay | 4PDT |
| Mounting - Relay | Socket |
| Contact Material | Silver Alloy, gold flashed |
| Body Height - Relay | 27.3 mm |
| Body Width - Relay | 40.6 mm |
| Body Depth - Relay | 41.8 mm |
| Standards | UL Listed; UL Recognized; CSA; CE |
| Series | Square D 8501R Miniature Series |
| Operating Temp. Range | -40-131°F |
| Pin Shape | spade |
| Switching Voltage | 300 V AC, 30 V DC |
| Operating Time | 20 ms - pick-up || 20 ms - drop-out |
| Status Indicator | No Indicator |
| Package Quantity | 1 |
