Relevador, 600VCA Voltaje de la bobina, 2 NA/2 NC; DPDT
| Item | Relay |
|---|---|
| Coil Volts | 600VAC |
| Body Depth - Relay | 2.31 in |
| Standards | UL listed file E78351 CCN NLDX; CSA; CE |
| Power Consumption - Relay | 2 W |
| Mounting - Relay | Panel Mount |
| Body Width - Relay | 2-1/2 in |
| Contact Form - Relay | 2 NO/2 NC; DPDT |
| Body Height - Relay | 3.12 in |
| Width | 2-1/2 in |
| Depth | 2.31 in |
| Height | 3.12 in |
| Mounting | Panel |
| Status Indicator | No Indicator |
| Device Short Name | type C |
| Range of Product | Power Relay 8501C |
| Awg Gauge | AWG 10 copper |
| Maximum Switching Voltage | 600 V AC |
| Hold-In Power Consumption In W | 2-2 W |
| Phase | 1 phase |
| Switch Function | DPDT |
| Ambient Air Temperature For Operation | -22-140°F |
| Line Rated Current | 30 A |
| Tightening Torque | 11-15 lbf.in |
| Mounting Support | panel mounting |
| Rated Power In Hp | 2.0 hp |
| Connections - Terminals | screw clamp terminal |
| Product or Component Type | power relay |
| Device Application | suited for controlling small single phase motors and other light loads |
| [Uc] Control Circuit Voltage | 24 V DC |
| Contacts Type And Composition | 2 NO, 2 NC |
| Horsepower Rating | 2.0 hp |
| Terminal Tightening Torque | 11 to 15 lbf.in (1.24 to 1.69 N.m) |
| Class Number | 8501 |
| Current Rating | 30 A |
| Control Circuit Voltage | 24 V DC |
| Switching Voltage | 600 V AC |
| Wire Range | AWG 10 copper |
| Operating Temp. Range | -22-140°F |
| Terminal Connects | Screw clamp terminal |
| Contact Composition | 2 NO/2 NC |
| Product Type | Power relay |
| Series | type C |
| Ambient Temperature Range - Operational | -22 to 140°F (-30 to 60°C) |
| Package Quantity | 1 |
