Safety Switch, Heavy Duty Safety Switch Ground Bar Assembly, 600V AC, 200A
| Item | Safety Switch |
|---|---|
| For Use With | Heavy Duty Safety Switch Ground Bar Assembly |
| Voltage | 600V AC |
| Amps | 200A |
| Max. Wire Size | 4 AWG |
| Min. Wire Size | 14 AWG |
| Includes | (2) Lugs, (2) Mounting Screws, Label |
| Line Rated Current | 200 A F5 || 200 A F7 |
| Awg Gauge | AWG 4 copper |
| Tightening Torque | 35-35 lbf.in 2.08-5.261 mm2² (AWG 14...AWG 10) || 35-35 lbf.in 5.261-5.261 mm2² (AWG 10) || 40-40 lbf.in 8.367-8.367 mm2² (AWG 8) || 45-45 lbf.in 13.30-21.15 mm2² (AWG 6...AWG 4) |
| Product Or Component Type | safety switch grounding bar |
| Series Name | heavy duty |
| Contact Form | 6PST |
| Compatible Product Type | Safety Switches |
| Product Type | Grounding Kit |
| IP Rating | Not Rated |
| Package Quantity | 1 |
