Arrancador 600Vac 45A Nema +Opciones, Clasificación NEMA no indicada, 220/240V CA, 2 Polos.
| Item | Starter 600Vac 45Amp Nema +Options |
|---|---|
| Coil Volts | 220/240V AC |
| Enclosure NEMA Rating | Not Rated |
| Auxiliary Contact Form | No Auxiliary Contacts |
| Starter Type | Non Reversing |
| Amps AC | 45 A |
| NEMA Size | 2 |
| Number of Poles | 2 |
| Depth | 125 mm |
| Height | 198 mm |
| Standards | UL Listed; CSA; NEMA |
| Features | Free of Mercury & Pvc |
| Width | 109 mm |
| Hz | 50/60 Hz |
| Enclosure Type | Open |
| Operating Voltage | 600V AC |
| Short Circuit Current Rating | 5 kA to 600 V AC (Circuit-breaker), 5 kA to 600 V AC (Fuse) |
| Phase | 1 phase |
| Auxiliary Contacts | Without |
| Horsepower Rating | 3 HP 115 V AC; 7.5 HP 230 V AC |
| Maximum Voltage Rating | 600 V AC |
| Type Of Overload | Melting alloy 1 |
| Coil Voltage | Hz |
| Control Circuit Type | Common control circuit |
| Terminal Type | Screw clamp terminals |
| Control Units | No control units |
| Pilot Light | Without pilot light |
| Pvc Free | Yes |
| Poles Description | 2P |
| Rated Power In Hp | 3 HP 115 V AC, 7.5 HP 230 V AC |
| [Uc] Control Circuit Voltage | 220 V AC 50 Hz, 240 V AC 60 Hz |
| Nema Degree of Protection | not rated (open device) |
| Range of Product | S |
| Thermal Overload Type | melting alloy 1 |
| Package Quantity | 1 |
