Magnet, Steel, 10ft. L, 10in D
| Material | Steel |
|---|---|
| Overall Length | 1 ft |
| Item | Chain |
| Tensile Strength | 3,950 lbf |
| Roller Chain Type | Conveyor |
| Temp. Range | -15 Degrees to 300 Degrees F |
| Industry Chain Size | C2042 |
| Pin Length | 0.375 |
| Chain Tensile Strength | 3,950 lb |
| Rivet End to Center Line | 0.32 in |
| Includes | (1) Connecting Link |
| Pin Link Plate Thickness | 0.06 in |
| Chain Roller Dia. | 0.55 in |
| Chain Type | Conveyer |
| Pin Type | Riveted |
| Chain Overall Width | 0.968 in |
| Roller Bushing Width | 0.312 in |
| Overall Width | 0.968 in |
| Pitch | 1 in |
| Chain Length | 10 ft |
| Inside Pin Dia. | 0.156 in |
| Roller Chain Item | Roller Chain |
| Industry Chain Pitch | 1 in |
| Roller Link Plate Height | 0.463 in |
| Number of Strands | 1 |
| Chain Material | Carbon Steel |
| Max. Allowable Load | 1,900 lb |
| Length | 10 ft |
| Roller Dia. | 0.55" |
| ANSI Chain Size | C2042 |
| Plate Thickness | 0.06 in |
| Features | This Single-Strand Roller Chain is Designed to Help Transfer Motion From One Set of Sprockets to Another |
| Inside Width | 0.313 in |
| Pin Hole Diameter | 0.156 in |
| Chain Construction | Riveted Pin |
| Minimum Operating Temperature | -15 Degrees F |
| Roller Diameter | 35/64 in |
| Maximum Operating Temperature | 300 Degrees F |
| Series | Conveyor |
| Chain Number | C2042 |
| Pin Contruction | Riveted Pin |
| Plate Height | 0.463 in |
| Pitch Type | Double Pitch |
| Working Load Limit | 1,900 lb |
| Heavy Series | No |
| Application | Attachment chain used in smaller scrap conveyors with Magnets or Drag flights on 6" or larger centers on 6" increments. |
| Country of Origin (subject to change) | Taiwan, Province of China |
| Package Quantity | 1 |
