Diamond Turning Insert, Diamond, 4, CNGG, .2, Carbide
| Item | Diamond Turning Insert |
|---|---|
| Insert Shape | Diamond |
| Insert Style | CNGG |
| Inscribed Circle | 4 |
| Insert Size | 430 |
| Chip-Breaker | Yes |
| Grade | AC520U |
| Corner Radius | .2 |
| Insert Material | Carbide |
| Insert Application | Finishing |
| Rake | 8 deg |
| ISO Number | CNGG120401NSU |
| Steel (P) Compatibility | No |
| Super Alloy (S) Compatibility | Yes |
| Hardened (H) Compatibility | No |
| No. of Edges | 4 |
| Relief Angle | 0 Degrees |
| Cast Iron (K) Compatibility | Yes |
| Non Ferrous (N) Compatibility | No |
| ANSI Number | CNGG430ESU-AC520U |
| Mounting Hole Dia. | 0.203 |
| For Use With | DCLN, MCLN, Toolholders, A-MCLN Boring Bars |
| Cutting Direction | Neutral |
| Insert Thickness | 3/16 in |
| Workpiece Compatibility | Cast Iron (K), Stainless (M), Super Alloy (S) |
| Mounting Style | Clamp |
| Coating | PVD, AlCrN, Super ZX TiAlN |
| Nose Radius | 0.004 in |
| Stainless (M) Compatibility | Yes |
| Finish - Machining | TiAlN+AlCrN |
| Chip-Breaker Style | Double |
| Included Angle | 80 Degrees |
| Material - Machining | Carbide |
| Insert Holding Type | Straight Hole |
| Number of Cutting Edges | 4 |
| Thickness | 3 |
| Shape | Rhombic |
| Manufacturer Grade | AC520U |
| Chip-Breaker Code | ESU |
| Primary Material Application ISO Code | P, M, S |
| Measurement System | Fractional Inch |
| Primary Material Application | Titanium, Nickel, Stainless Steel, Steel |
| ANSI Code | CNGG430ESU |
| Clearance Angle | 0 deg |
| Coating Process | PVD |
| Features | Excellent Fracture Resistance |
| Cutting Application | Turning |
| Material | Carbide |
| Application | Finishing |
| Style | CNGG |
| Package Quantity | 1 |
