12.0000" OAL, Pin & Clamp, Uses TNMG 332 Inserts
| Minimum Bore Diameter (Decimal Inch) | 1.2000 |
|---|---|
| Toolholder Style | A-MTFN |
| Tool Material | Steel |
| Insert Compatibility | TNMG 332 |
| Hand of Holder | Left Hand |
| Shank Diameter (Inch) | 1 |
| Overall Length (Decimal Inch) | 12.0000 |
| Compatible Insert Size Code | 332 |
| Insert Holding Method | Pin & Clamp |
| Compatible Insert Shape | Triangle |
| Rake | Positive |
| Rake Angle | 15.00 |
| Lead Angle | 0 |
| Insert Inscribed Circle (Inch) | 3/8 |
| Multi-use Tool | No |
| Cutting Tool Application | Boring |
| Center to Cutting Edge (Decimal Inch) | 0.6400 |
| Coolant Hole Thread Size (Inch) | 1/4-18 NPT |
| UNSPSC Code | 23241601 |
| Insert Thickness (Inch) | 3/16 |
| Coolant Through | Yes |
| Country of Origin | UNITED STATES |
| MSC Number | MSC# 53946570 |
