Screw, Uses DPMT 32.52 Inserts
| Minimum Bore Diameter (Decimal Inch) | 1.3000 |
|---|---|
| Toolholder Style | A-SDXP |
| Tool Material | Steel |
| Insert Compatibility | DPMT 32.52 |
| Hand of Holder | Left Hand |
| Shank Diameter (Inch) | 1 |
| Overall Length (Inch) | 12-3/4 |
| Compatible Insert Size Code | 32.52 |
| Insert Holding Method | Screw |
| Compatible Insert Shape | Diamond |
| Rake | Neutral |
| Rake Angle | 0.00 |
| Lead Angle | 5 |
| Insert Inscribed Circle (Inch) | 3/8 |
| Compatible Insert Thickness (Decimal Inch) | 0.1560 |
| Multi-use Tool | No |
| Cutting Tool Application | Boring |
| Center to Cutting Edge (Decimal Inch) | 0.7500 |
| Coolant Hole Thread Size (Inch) | 1/4-18 NPT |
| Standards | ANSI-ISO |
| UNSPSC Code | 23241601 |
| Insert Thickness (Inch) | 5/32 |
| Coolant Through | Yes |
| Country of Origin | UNITED STATES |
| MSC Number | MSC# 53946521 |
