Uses (2) AOMT17;AOET17 Inserts, Through Coolant, 3.947" OAL
| Cutting Diameter | 1 |
|---|---|
| Overall Length (Decimal Inch) | 3.9470 |
| Maximum Depth of Cut (Decimal Inch) | 0.5910 |
| Cutter Style | WEZ |
| Shank Type | Weldon Flat |
| Shank Diameter (Inch) | 1 |
| Tool Material | Steel |
| Series | WEZ |
| Lead Angle | 90 |
| Shank Length (Decimal Inch) | 2.2810 |
| Insert Compatibility | AOMT17; AOET17 |
| Hand of Holder | Right Hand |
| UNSPSC Code | 27112803 |
| Manufacturers Catalog Number | WEZ31000EW02 |
| Number Of Cutter Inserts | 2 |
| Coolant Through | Yes |
| Country of Origin | Japan |
| undefined | undefined |
| MSC Number | MSC# 11304334 |
