| System Size | Universal |
|---|---|
| Maximum Depth of Cut (Decimal Inch) | 0.2756 |
| Maximum Depth of Cut (mm) | 7.00 |
| Minimum Groove Width (Decimal Inch) | 0.0492 |
| Minimum Groove Width (mm) | 1.25 |
| Maximum Groove Width (Decimal Inch) | 0.0492 |
| Maximum Groove Width (mm) | 1.25 |
| Cutting Direction | Left Hand |
| Modular Head Style | Blade Holder Head |
| Compatible Insert Style | GCMN125005 |
| Compatible Insert Size Code | GCMN |
| Series | PSZ Turn |
| Center to Cutting Edge (mm) | 0.00 |
| Center to Cutting Edge (Decimal Inch) | 0.0000 |
| Blade Style Compatibility | None |
| Head Length Projection (Decimal Inch) | 0.8661 |
| Coolant Through | Yes |
| Head Length Projection (mm) | 22.00 |
| UNSPSC Code | 23242100 |
| Country of Origin | Germany |
| MSC Number | MSC# 84112408 |
