Speciality Turning Insert, Parallelogram, 1.5, ZNEX, 1, CBN
| Item | Speciality Turning Insert |
|---|---|
| Insert Shape | Parallelogram |
| Insert Style | ZNEX |
| Inscribed Circle | 1.5 |
| Insert Size | 621 |
| Chip-Breaker | Yes |
| Grade | BN2000 |
| Corner Radius | 1 |
| Insert Material | CBN |
| Insert Application | Finishing |
| Rake | 10 deg |
| ISO Number | NU-ZNEX040104 |
| Steel (P) Compatibility | Yes |
| No. of Edges | 1 |
| Super Alloy (S) Compatibility | Yes |
| For Use With | Toolholders, Boring Bars |
| Hardened (H) Compatibility | Yes |
| Cutting Direction | Neutral |
| ANSI Number | NUZNEX621-BN2000 |
| Non Ferrous (N) Compatibility | No |
| Workpiece Compatibility | Cast Iron (K), Hardened (H), Steel (P), Super Alloy (S) |
| Insert Thickness | 1/16 in |
| Nose Radius | 0.0156 in |
| Coating | PVD |
| Mounting Style | Top and hole Clamping |
| Mounting Hole Dia. | 0.09 in |
| Stainless (M) Compatibility | No |
| Cast Iron (K) Compatibility | Yes |
| Depth of Cut | 0.0150 in |
| Manufacturer Grade | BN2000 |
| Hole Type | Through Hole |
| Cutting Application | Boring |
| Included Angle | 80 Degrees |
| General Shape | 80 Degrees Special Shape |
| Clearance Angle | 7 deg |
| Through Hole Inside Dia. | 0.09 in |
| Features | For Use with BNZ Holders, High Degree of Fracture and Wear Resistance |
| Cutting Material Coverage | Full Tip |
| ANSI Code | NU-ZNEX621 |
| Material - Machining | CBN |
| Shape | 80 Degrees Special Shape |
| Chip-Breaker Style | 10 Degrees Rake Angle |
| Primary Material Application ISO Code | H10 - H20 |
| Measurement System | Fractional Inch |
| Finish - Machining | Bright |
| Thickness | 1/16 in |
| Primary Material Application | Hardened Steel |
| Package Quantity | 1 |
