TiAlSiN Finish, Neutral, 0.1398" Long, 0.3750" Inscribed Circle, 0.0156" Corner Radius, 80 deg C - Diamond (Rhombic) 80-Deg, Series AC5000S
| Insert Style | CCGT |
|---|---|
| ISO Size Code | 09T304 |
| ANSI Size Code | 32.51 |
| Insert Shape | C - Diamond (Rhombic) 80-Deg |
| Included Angle | 80 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Inscribed Circle (Inch) | 3/8 |
| Corner Radius (Decimal Inch) | 0.0156 |
| Insert Material | Carbide |
| Manufacturer Grade | AC5025S |
| Coating/Finish | TiAlSiN |
| Relief Angle | 7 |
| Insert Thickness (Decimal Inch) | 0.1563 |
| Insert Hand | Neutral |
| Series | AC5000S |
| Grade Characteristics | Special, Super Alloys (S) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Hardened Materials (H) - High Wear Resistance to Moderate Wear-Resistance and Toughness |
| Chip Breaker Operation | Light Machining; Medium Machining |
| Side Clearance | Positive |
| Insert Shape Code | C |
| Hole Diameter (Decimal Inch) | 0.1732 |
| ISO Insert Code | CCGT09T304 |
| ANSI Insert Code | CCGT32.51 |
| Insert Holding Method | Screw |
| Clearance Code | C |
| Tolerance Code | G |
| Coating Process | PVD |
| Rake | Positive |
| Insert Length (Decimal Inch) | 0.1398 |
| Primary Workpiece Material Code | S; H |
| Secondary Workpiece Material | Superalloy |
| Secondary Workpiece Material Code | S |
| Iso Code | CCGT09T304MN-SI |
| Standards | ISO 13399; ANSI |
| Manufacturers Catalog Number | CCGT32.51MESIAC5025S |
| Material Grade | S20 |
| Proprietary Coating Designation | Absotech Bronze |
| Chip Breaker | MESI |
| Rake Angle | 15 |
| Full Radius | No |
| UNSPSC Code | 23242105 |
| Insert Size Code | 32.51 |
| Country of Origin | Japan |
| MSC Number | MSC# 12595146 |
