02P MTA156 CONN ASSY 18AWG LF
| Wire Range | 0.8 to 0.9 mm² |
|---|---|
| Insulation Color | Orange |
| Connection Type | Locking Lance, Socket, Insulation Displacement Crimp |
| Features | Strain Relief |
| Standards | UL, CSA Listed |
| Max. Temp. | 221 deg F |
| Item | Connector |
| Max. Voltage | 600 V AC |
| Wire Type | Stranded, Discrete Wire |
| Terminal Type | Feed Through Receptacle |
| Overall Length | 0.468 in |
| Connection Material | Copper Alloy |
| Application | Power, Wire and Cable |
| Terminal Orientation | 90 ° |
| Contact Plating Material | Nickel |
| Insulation Dia | 0.095 in |
| Package Quantity | 1 |
