1.0MM W T B RECPT 4POS HOUSING
| Item | Connector |
|---|---|
| Number of Rows | 1 |
| Material | Thermoplastic |
| Width | 0.1968 in |
| Color | White |
| Height | 2.8 mm |
| Application | Signal, Power |
| Length | 7 mm |
| Max. Temp. | 105 deg C |
| Terminal Type | Crimp |
| Contact Type | Socket |
| Max. Voltage | 50V AC/DC |
| Flammability Rating | UL 94 V-0 |
| Connector Type | Receptacle |
| Hole Center to Center | 1 mm |
| Current Rating | 1 A |
| Min. Single Wire Size | 32 AWG |
| Connector Terminates To | Cable, Wire |
| Max. Single Wire Size | 28 AWG |
| Number of Contacts | 4 |
| Package Quantity | 1 |
