Conector de tarjeta, 14 contactos, 2 filas, macho, recto, paso de 0.1 pulgadas, terminal de soldadura, guía.
| Item | Connector |
|---|---|
| Color | Black |
| Max. Voltage | 250 V AC |
| Application | Signal |
| Height | 13.94 mm |
| Length | 1.46 in |
| Connector Type | Header |
| For Use With | AMP-Latch Receptacle |
| Material | Nylon |
| Hole Center to Center | 2.54 mm |
| Terminal Type | Through Hole |
| Connection Material | Phosphor Bronze |
| Max. Temp. | 105 deg C |
| Number of Rows | 2 |
| Contact Finish | Gold Plated, Gold Flash over Palladium Nickel |
| Flammability Rating | UL 94 V-0 |
| Contact Plating Thickness | 15µin |
| Terminal Finish | Tin Plated |
| Contact Type | Pin |
| Connector Terminates To | Printed Circuit Board |
| Current Rating | 1 A |
| Number of Contacts | 14 |
| Package Quantity | 1 |
