Board Connector, 3 Contact(S), 1 Row(S), Male, Straight, Solder Terminal, Natural Insulator
| Item | Connector |
|---|---|
| Color | Natural |
| Max. Single Wire Size | 22 AWG |
| Min. Single Wire Size | 28 AWG |
| Max. Voltage | 125V AC/DC |
| Width | 0.228 in |
| Height | 0.267 in |
| Length | 7.8 mm |
| Connector Type | Header |
| For Use With | Receptacle Connector |
| Connection Material | Brass |
| Hole Center to Center | 2 mm |
| Wire Type | Discrete |
| Max. Temp. | 105 deg C |
| Features | Shrouded |
| Material | Nylon |
| Terminal Type | Through Hole - Solder |
| Contact Type | Pin |
| Contact Plating Thickness | 1 µm |
| Number of Contacts | 3 |
| Flammability Rating | UL 94 V-0 |
| Current Rating | 4 A |
| Number of Rows | 1 |
| Contact Finish | Tin Plated |
| Terminal Finish | Tin Plated |
| Package Quantity | 1 |
