Board Connector, 8 Contact(S), 1 Row(S), Male, Straight, Solder Terminal, Blue Insulator, Plug
| Color | Blue |
|---|---|
| Item | Header |
| Max. Voltage | 250V AC/DC |
| Application | Power |
| Width | 0.421 in |
| Length | 31.62 mm |
| Height | 8.2 mm |
| Features | Unshrouded |
| Hole Center to Center | 3.96 mm |
| Material | Glass-Filled PBT |
| For Use With | Plug Housing |
| Connection Material | Brass |
| Terminal Type | Through Hole - Solder |
| Max. Temp. | 105 deg C |
| Current Rating | 8 A |
| Terminal Finish | Tin Plated |
| Number of Contacts | 8 |
| Contact Finish | Tin Plated |
| Connector Terminates To | Printed Circuit Board |
| Contact Type | Pin, Tab |
| Number of Rows | 1 |
| Contact Plating Thickness | 1 µm |
| Flammability Rating | UL 94 V-0 |
| Package Quantity | 1 |
