Combination Line Connector, 3 Contact(S), Female, Crimp Terminal, Plug
| Item | Plug |
|---|---|
| Color | Natural |
| Min. Single Wire Size | 24 AWG |
| Number of Rows | 1 |
| Max. Single Wire Size | 16 AWG |
| Max. Voltage | 300V AC/DC |
| Height | 9.5 mm |
| Application | Signal, Power |
| Length | 18.6 mm |
| Material | Nylon |
| Terminal Type | Crimp |
| Connection Material | Copper Alloy |
| Hole Center to Center | 6.5 mm |
| For Use With | 1747049-1 Header Assembly |
| Max. Temp. | 105 deg C |
| Connector Terminates To | Cable, Wire |
| Contact Plating Thickness | 0.8 um |
| Contact Finish | Tin Plated |
| Number of Contacts | 3 |
| Current Rating | 9 A |
| Terminal Finish | Tin Plated |
| Contact Type | Receptacle |
| Flammability Rating | UL 94 V-0 |
| Package Quantity | 1 |
